Cube-relief PET tiles give the strongest geometric statement of the 3D family — deep shadows, clean edges, and the full acoustic performance of solid polyester fibre beneath.
| Property | Value |
|---|---|
| Structure | 100% polyester fibre, routed relief |
| Material | 100% polyester fibre (recycled PET) |
| Thickness | 9 / 12 mm |
| Size | Within 2400 × 1200 mm (custom shapes available) |
| Finish | Multiple colours available |
PET panel data as published in the MST product catalogue: 12 mm and 9 mm thicknesses.
| Frequency (Hz) | 12 mm | 9 mm |
|---|---|---|
| 100 | 0.10 | 0.11 |
| 125 | 0.13 | 0.31 |
| 160 | 0.35 | 0.32 |
| 200 | 0.49 | 0.45 |
| 250 | 0.63 | 0.55 |
| 315 | 0.77 | 0.69 |
| 400 | 0.81 | 0.72 |
| 500 | 0.83 | 0.79 |
| 630 | 0.84 | 0.81 |
| 800 | 0.93 | 0.88 |
| 1000 | 0.95 | 0.91 |
| 1250 | 0.88 | 0.82 |
| 1600 | 0.81 | 0.69 |
| 2000 | 0.75 | 0.66 |
| 2500 | 0.73 | 0.71 |
| 3150 | 0.70 | 0.68 |
| 4000 | 0.69 | 0.61 |
| 5000 | 0.67 | 0.59 |
Octave-band average of the 250–2000 Hz bands (NRC) ≈ 0.80. Coefficients are quoted for the mounting described above; a different cavity depth or backing moves the curve, so confirm the build-up with us before fixing the specification.
Feature walls in lobbies, studios, media rooms and showrooms.
| Item | Detail |
|---|---|
| Minimum order quantity | 200 m² |
| Production lead time | 15–25 working days from order confirmation |
| Packaging | Compressed bale, shrink-wrapped |
| Container loading | 20′ GP ≈ 1,500 m² |
| Terms | EXW Shanghai · FOB Shanghai · CIF on request |
| Payment | 30% deposit with order, balance against B/L copy by T/T; L/C at sight on request |
Component test reports are issued to our manufacturing partners rather than to MST. Authorised copies, including laboratory and certificate numbers, are released with every quotation.
A swatch pack of the standard 3D shapes and colours is despatched free of charge within 7 working days.
Email your drawing, panel schedule or a square-metre count to sales@mstacoustics.com, or send the enquiry form on this page. We reply within one working day with pricing, lead time and freight options. Datasheets, colour charts and installation guides are collected in our technical resources library.
Is the cube pattern heavy?
No — PET is light; the panel carries its own weight on adhesive.
Can it be UV printed?
Yes — CNC cutting and UV printing are both available on the PET body.
How is it cleaned?
Vacuum or compressed air; the fibre does not shed.
